12.1m Self Propelled Electric Articulating Boom Lifts Za20jert-Li Aerial Work Platform

1 / 5

12.1m Self Propelled Electric Articulating Boom Lifts Za20jert-Li Aerial Work Platform

Customization:	Available
After-sales Service:	Provided
Warranty:	Provided

Send Inquiry

Product Description

📑 Basic Information

Model NO.

ZA20JERT-Li

Application

Workshop, Shipboard, Warehouse, Building

Lift Mechanism

Articulated Lift

Driven Type

Work Height

21.38m

Platform Height

19.38m

Certification

GS, CE, RoHS, ISO 9001

Carrying Capacity

Middle-Level (250kg/360kg)

🚀 Product Description

🔹

Superior Performance: Provides greater work height of 21.38m and lift capacity of 250kg/360kg compared to competitors.

🔹

Efficiency: Fast lift system directly lowers the boom from the highest position to the ground without folding, improving work efficiency.

🔹

Advanced Drive System: Accurate traveling AC drive system provides strong power, stable control, and maintenance-free operation.

🔹

Lithium Battery Technology: Large-capacity lithium battery features long-lasting life with up to 2500 charge cycles and a 5-year warranty.

🔹

Safety & Control: Independent auxiliary power system for secure application and large reduction ratio reducer for stronger gradeability.

📊 Technical Parameters

Work Height	21.38m
Platform Height	19.38m
Horizontal Outreach	12.1m
Up and Over Height	8.25m
Stowed Length (A)	8.8m
Stowed Width (B)	2.46m
Stowed Height (C)	2.52m
Platform Length (D)	2.44m
Platform Width (E)	0.91m
Wheelbase (F)	2.52m
Ground Clearance (G)	0.4m

❓ Frequently Asked Questions

What is the maximum working height of the ZA20JERT-Li?

The ZA20JERT-Li provides a maximum work height of 21.38m and a platform height of 19.38m.

What type of battery does this boom lift use?

It is equipped with a large-capacity lithium battery that supports up to 2500 charge/discharge cycles and comes with a 5-year warranty.

Is the drive system maintenance-free?

Yes, the accurate and efficient AC drive system is designed to be maintenance-free while providing strong power and stable control.

How does the fast lift system improve efficiency?

The fast lift system allows the boom to be lowered directly from the highest position to the ground without needing to fold it first.

What safety certifications does this product hold?

The equipment is certified by GS, CE, RoHS, and ISO 9001 standards, ensuring high safety and quality.

What is the lift capacity of this model?

The ZA20JERT-Li offers a flexible lift capacity ranging from 250kg to 360kg.
